Features

SHD series unit type Harmonic Drive®, which inherits the excellent performance characteristics of the SHF Series, weight and configuration compactness, and comprised of a cross roller bearing of high moment stiffness has been taken to new level.
SHD series unit type Harmonic Drive® are offered in a series of six different sizes, opening up new possibilities motion control speed reducers.

• Thickness has been reduced to 1/2 that of the SHF series
• Torque capacity is 70% of the SHF series
• Torsional rigidity is 80 to 90% of SHF series
• Hollow-Shaft construction
• Comprised in Cross Roller Bearing of High moment stiffness

Models & Symbols
1
1. Type: SHD series
2. Size: 14, 17, 20, 25, 32, 40
3. Reduction ratio: 50, 100, 160
4. Models and symbols:
    • 2SH = Simple unit type
    (SHD series is only unit type)
5. Special specification (Suffix "SP" is only special specification)

  Specification
Size
Reduction ratio
Rated torque at 2000r/min
Allowable peak torque at start and stop
Allowable average torque
Allowable maximum momentary torque
Maximum input speed (Grease lubrication)
N·m
N·m
N·m
N·m
r/min
14
50
3.7
12
4.8
23
8500
100
5.4
19
7.7
35
17
50
11
23
18
48
7300
100
16
37
27
71
20
50
17
39
24
69
6500
100
28
57
34
95
160
28
64
34
95
25
50
27
69
38
127
5600
100
47
110
75
184
160
47
123
75
204
32
50
53
151
75
268
4800
100
96
233
151
420
160
96
261
151
445
40
50
96
281
137
480
4000
100
185
398
260
700
160
206
453
316
765

   Allowable momentaly peak torque (*) is limited by the clamping torque of the flexspline.

Product Drawing
2
(Unit:mm)
Symbol /Size
14
17
20
25
32
40
øA h6
49
59
69
84
110
132
B
17.5
18.5
19
22
27.9
33
øC H7
11
15
20
24
32
40
øD h7
70
80
90
110
142
170
Mass(kg)
0.33
0.42
0.52
0.91
1.87
3.09

   Please confirm dimensions and specification with the drawing issued by Harmonic Drive Systems.
